★New energy cutting machine：
Suitable for new energy, carbon fiber film, FPC flexible circuit board factory.
PET film, PVC film, PP film, reflective film, pearl film, copper foil, aluminum film, mobile phone protective film, reflective sheet, double-sided adhesive, dust screen, 3M adhesive, key switch, flexible circuit board (FPC), mobile phone and plate precision die-cutting accessories, hot melt adhesive, thermal conductive materials, coated paper, grey board paper, carbon fiber cloth, etc.
♦Main technical parameters
| Model | JR-0906TD | JR-1209TD | JR-1512TD | JR-1812TD |
| Cutting range(mm) | 900*600 | 1200*900 | 1500*1200 | 1800*1200 |
| Max Speed(mm/s) | 1500 | 1500 | 1500 | 1500 |
| Max Thickness(mm) | 2 | 2 | 2 | 2 |
| Cutting accuracy (mm) | ≤0.05 | ≤0.1 | ≤0.1 | ≤0.1 |
| Min Dia. of round(mm) | 1 | 1 | 1 | 1 |
| Output port | Ethernet port | |||
| File format | HP-GL compatible formats, including DXF, CDR, AI and other common formats | |||
| Fixed way | Vacuum adsorption | |||
| Voltage | AC 380V±10% or 220V±10% 50HZ/60HZ, can also be customized according to the customer’s voltage | |||
| Overall dimension(mm) | 1450*1050*950 | 1750*1350*950 | 2050*1650*950 | 2450*1650*950 |
| Total weight(Kg) | 220 | 280 | 350 | 480 |
